Custom Micro Perforated Aluminum Honeycomb Panel, Grade A Fireproof Acoustic Honeycomb Board for Concert Hall & Meeting Room

Custom Micro Perforated Aluminum Honeycomb Panel, Grade A Fireproof Acoustic Honeycomb Board for Concert Hall & Meeting Room


Availability:

Quantity:



Inquire Add to Basket

Perforated aluminum honeycomb panel is high-temperature composited with perforated aluminum face sheet, aluminum honeycomb core and back sheet. It features sound absorption & noise reduction, Grade A fire resistance, light weight and high rigidity. Custom round holes, square holes and micro holes are available with PVDF, powder coating or wood grain finish. Widely used for facade, ceiling, theater and transportation hub acoustic decoration. Foshan direct factory supports full-size and special shape customization.

Code:
7616999000

Perforated Aluminum Honeycomb Panel Acoustic honeycomb panel Sound absorbing aluminum honeycomb panel PVDF honeycomb facade pane Perforated honeycomb ceiling panel Aluminum honeycomb wall cladding Micro perforated honeycomb sheet Fireproof aluminum composite honeycomb board

Product Description

4-layer composite structure: perforated aluminum face sheet + sound-absorbing non-woven fabric/fiberglass cotton + hexagonal aluminum honeycomb core + aluminum back sheet. Bonded integrally with eco-friendly adhesive under high temperature and high pressure. The closed honeycomb cavity absorbs sound waves through micro holes to reduce noise, with NRC sound absorption coefficient up to 0.6-0.9.

Core Advantages

1. Light weight & high rigidity: weight only 3–7kg per square meter, 1/5 weight of solid aluminum sheet, no deformation for large panels, reduce building load

2. Professional sound absorption: closed honeycomb cavity eliminates reverberation, ideal acoustic material for theaters and meeting rooms

3. Grade A fireproof: fully aluminum non-combustible material, moisture-proof, mildew-proof and anti-corrosion, suitable for indoor and outdoor use

4. Heat & sound insulation: hollow honeycomb layer blocks heat transfer, sound insulation over 30dB, energy saving

5. Easy installation & maintenance: dry hanging / hook ceiling system, single panel detachable for pipeline inspection

6. Highly customizable: perforation pattern, radian, special shape, column cladding and LOGO engraving can be produced

7. Eco-friendly & durable: formaldehyde-free and recyclable; outdoor PVDF coating resists acid rain and fading

Application Scenarios

- Acoustic spaces: concert halls, theaters, cinemas, studios, lecture halls, meeting rooms, libraries

- Transportation hubs: sound-absorbing wall & ceiling for airports, high-speed stations, subway stations, tunnels

- Commercial public buildings: hotel lobbies, shopping malls, exhibition halls, hospitals, schools, stadiums

- Building exterior: facade, door head, curved exterior wall, column cladding, canopy decoration

- Special fields: ship, yacht, rail transit interior, equipment sound insulation cover

Specification of honeycomb panel
Total Thickness	5mm,10mm,12mm,15mm,18mm,20mm,25mm or Customized Made.
Available Surface Aluminum Sheet	AA1100/AA3003/AA5052, etc.
Aluminum sheet Thickness	0.3mm,0.5mm,0.6mm,0.7mm,0.8mm,0.9mm,1.0mm,1.5mm,2.0mm,etc
Surface Treatment	Mill finish, PVDF, PE/Polyester, Wooden, Brushed, Polished.
Applications	Wall Cladding, Ceiling, Partition, Ship, Door，Aviation, High-speed rail, Train, Subway, Roof tent, Truck body panel.
*Panel Size(LW)**	Regular Size(mm):2440(L)*1220(W)
*Panel Size(LW)**	Max Size(mm):8000(L)1800(W);6000(L)2000(W)
Panel shape	Flat，Curved，Column， As per drawings
HS Code	76169990
